No logo in the Gnome control center

Hi,

I am a pedantic esthete. How to change it to be a logo? :slight_smile:

1 Like

Thanks for your trouble in solving the problem, but it doesn't work.

Post your terminal/konsole in- and output as text (no pictures) from:

garuda-inxi

Without it, you will not receive any help from the Garuda team or your topic is likely to be closed without notice.

Before you open a new help request, read relevant sections of the Arch and Garuda wiki.
Thoroughly search your issue and any error messages in the forum and on the web.

Report everything you have already attempted to solve your problem.

1 Like
garuda-inxi
System:
  Kernel: 5.17.3-zen1-1-zen arch: x86_64 bits: 64 compiler: gcc v: 11.2.0
    parameters: BOOT_IMAGE=/@/boot/vmlinuz-linux-zen
    root=UUID=9be3901c-8d10-429a-99ce-98ced9f7d5bb rw [email protected]
    quiet quiet splash rd.udev.log_priority=3 vt.global_cursor_default=0
    loglevel=3
  Desktop: GNOME v: 42.0 tk: GTK v: 3.24.33 wm: gnome-shell dm: GDM v: 42.0
    Distro: Garuda Linux base: Arch Linux
Machine:
  Type: Laptop System: Acer product: Nitro AN517-51 v: V1.33
    serial: <superuser required>
  Mobo: CFL model: Superb_CFS v: V1.33 serial: <superuser required>
    UEFI: Insyde v: 1.33 date: 11/17/2020
Battery:
  ID-1: BAT1 charge: 44.1 Wh (100.0%) condition: 44.1/57.5 Wh (76.7%)
    volts: 16.6 min: 15.4 model: LGC AP18E8M type: Li-ion serial: <filter>
    status: full
CPU:
  Info: model: Intel Core i5-9300H bits: 64 type: MT MCP arch: Coffee Lake
    family: 6 model-id: 0x9E (158) stepping: 0xA (10) microcode: 0xEC
  Topology: cpus: 1x cores: 4 tpc: 2 threads: 8 smt: enabled cache:
    L1: 256 KiB desc: d-4x32 KiB; i-4x32 KiB L2: 1024 KiB desc: 4x256 KiB
    L3: 8 MiB desc: 1x8 MiB
  Speed (MHz): avg: 1856 high: 3350 min/max: 800/4100 scaling:
    driver: intel_pstate governor: powersave cores: 1: 3350 2: 3290 3: 2600
    4: 1880 5: 1290 6: 844 7: 800 8: 800 bogomips: 38400
  Flags: avx avx2 ht lm nx pae sse sse2 sse3 sse4_1 sse4_2 ssse3 vmx
  Vulnerabilities:
  Type: itlb_multihit status: KVM: VMX disabled
  Type: l1tf
    mitigation: PTE Inversion; VMX: conditional cache flushes, SMT vulnerable
  Type: mds mitigation: Clear CPU buffers; SMT vulnerable
  Type: meltdown mitigation: PTI
  Type: spec_store_bypass
    mitigation: Speculative Store Bypass disabled via prctl
  Type: spectre_v1
    mitigation: usercopy/swapgs barriers and __user pointer sanitization
  Type: spectre_v2 mitigation: Retpolines, IBPB: conditional, IBRS_FW,
    STIBP: conditional, RSB filling
  Type: srbds mitigation: Microcode
  Type: tsx_async_abort status: Not affected
Graphics:
  Device-1: Intel CoffeeLake-H GT2 [UHD Graphics 630]
    vendor: Acer Incorporated ALI driver: i915 v: kernel ports: active: eDP-1
    empty: none bus-ID: 00:02.0 chip-ID: 8086:3e9b class-ID: 0300
  Device-2: NVIDIA TU117M [GeForce GTX 1650 Mobile / Max-Q]
    vendor: Acer Incorporated ALI driver: nvidia v: 510.60.02
    alternate: nouveau,nvidia_drm pcie: gen: 3 speed: 8 GT/s lanes: 16 ports:
    active: none empty: HDMI-A-1 bus-ID: 01:00.0 chip-ID: 10de:1f91
    class-ID: 0300
  Device-3: Quanta HD Webcam type: USB driver: uvcvideo bus-ID: 1-5:2
    chip-ID: 0408:a060 class-ID: 0e02 serial: <filter>
  Display: wayland server: X.org v: 1.21.1.3 with: Xwayland v: 22.1.1
    compositor: gnome-shell driver: X: loaded: modesetting,nvidia gpu: i915
    display-ID: 0
  Monitor-1: eDP-1 model: BOE Display 0x0839 built: 2018 res: 1920x1080
    dpi: 128 gamma: 1.2 size: 382x215mm (15.04x8.46") diag: 438mm (17.3")
    ratio: 16:9 modes: 1920x1080
  OpenGL: renderer: Mesa Intel UHD Graphics 630 (CFL GT2)
    v: 4.6 Mesa 22.0.1 direct render: Yes
Audio:
  Device-1: Intel Cannon Lake PCH cAVS vendor: Acer Incorporated ALI
    driver: snd_hda_intel v: kernel
    alternate: snd_soc_skl,snd_sof_pci_intel_cnl bus-ID: 00:1f.3
    chip-ID: 8086:a348 class-ID: 0403
  Device-2: NVIDIA vendor: Hewlett-Packard driver: snd_hda_intel v: kernel
    pcie: gen: 3 speed: 8 GT/s lanes: 16 bus-ID: 01:00.1 chip-ID: 10de:10fa
    class-ID: 0403
  Sound Server-1: ALSA v: k5.17.3-zen1-1-zen running: yes
  Sound Server-2: PulseAudio v: 15.0 running: no
  Sound Server-3: PipeWire v: 0.3.50 running: yes
Network:
  Device-1: Intel Cannon Lake PCH CNVi WiFi driver: iwlwifi v: kernel
    bus-ID: 00:14.3 chip-ID: 8086:a370 class-ID: 0280
  IF: wlp0s20f3 state: up mac: <filter>
  Device-2: Realtek RTL8111/8168/8411 PCI Express Gigabit Ethernet
    vendor: Acer Incorporated ALI driver: r8169 v: kernel pcie: gen: 1
    speed: 2.5 GT/s lanes: 1 port: 3000 bus-ID: 08:00.0 chip-ID: 10ec:8168
    class-ID: 0200
  IF: enp8s0 state: down mac: <filter>
Bluetooth:
  Device-1: Intel Bluetooth 9460/9560 Jefferson Peak (JfP) type: USB
    driver: btusb v: 0.8 bus-ID: 1-14:4 chip-ID: 8087:0aaa class-ID: e001
  Report: bt-adapter ID: hci0 rfk-id: 4 state: down
    bt-service: enabled,running rfk-block: hardware: no software: no
    address: <filter>
Drives:
  Local Storage: total: 1.03 TiB used: 276.13 GiB (26.2%)
  SMART Message: Required tool smartctl not installed. Check --recommends
  ID-1: /dev/nvme0n1 maj-min: 259:0 vendor: Kingston model: SA2000M8500G
    size: 465.76 GiB block-size: physical: 512 B logical: 512 B
    speed: 31.6 Gb/s lanes: 4 type: SSD serial: <filter> rev: S5Z42105
    temp: 22.9 C scheme: MBR
  ID-2: /dev/nvme1n1 maj-min: 259:2 vendor: Kingston
    model: RBUSNS8154P3512GJ1 size: 476.94 GiB block-size: physical: 512 B
    logical: 512 B speed: 15.8 Gb/s lanes: 2 type: SSD serial: <filter>
    rev: E8FK12.3 temp: 24.9 C scheme: GPT
  ID-3: /dev/sda maj-min: 8:0 vendor: PNY model: CS900 120GB SSD
    size: 111.79 GiB block-size: physical: 512 B logical: 512 B speed: 6.0 Gb/s
    type: SSD serial: <filter> rev: 0613 scheme: GPT
Partition:
  ID-1: / raw-size: 46.79 GiB size: 46.79 GiB (100.00%)
    used: 14.94 GiB (31.9%) fs: btrfs dev: /dev/nvme1n1p2 maj-min: 259:4
  ID-2: /boot/efi raw-size: 300 MiB size: 299.4 MiB (99.80%)
    used: 28.7 MiB (9.6%) fs: vfat dev: /dev/nvme1n1p1 maj-min: 259:3
  ID-3: /home raw-size: 429.86 GiB size: 429.86 GiB (100.00%)
    used: 261.16 GiB (60.8%) fs: btrfs dev: /dev/nvme1n1p3 maj-min: 259:5
  ID-4: /var/log raw-size: 46.79 GiB size: 46.79 GiB (100.00%)
    used: 14.94 GiB (31.9%) fs: btrfs dev: /dev/nvme1n1p2 maj-min: 259:4
  ID-5: /var/tmp raw-size: 46.79 GiB size: 46.79 GiB (100.00%)
    used: 14.94 GiB (31.9%) fs: btrfs dev: /dev/nvme1n1p2 maj-min: 259:4
Swap:
  Kernel: swappiness: 133 (default 60) cache-pressure: 100 (default)
  ID-1: swap-1 type: zram size: 15.46 GiB used: 10.4 MiB (0.1%)
    priority: 100 dev: /dev/zram0
Sensors:
  System Temperatures: cpu: 43.0 C pch: 45.0 C mobo: N/A
  Fan Speeds (RPM): N/A
Info:
  Processes: 380 Uptime: 1h 40m wakeups: 3 Memory: 15.46 GiB
  used: 3.62 GiB (23.4%) Init: systemd v: 250 tool: systemctl Compilers:
  gcc: 11.2.0 Packages: pacman: 1225 lib: 373 Shell: Bash v: 5.1.16
  running-in: gnome-terminal inxi: 3.3.15
Garuda (2.6.1-3):
  System install date:     2022-04-16
  Last full system update: 2022-04-16 ↻
  Is partially upgraded:   No
  Relevant software:       NetworkManager
  Windows dual boot:       Probably (Run as root to verify)
  Snapshots:               Snapper

What doesn't work? I am not seeing the description of your attempt to fix the issue.

SGS posted a photo from google. This advice is great because I wouldn't think of it...

The tutorials are not working (UBUNTU) and are not solving the problem. If that were the case, I wouldn't be writing here.

Neither this:

This issue affects every version of Garuda Gnome (current.iso)

So please do not paste the photo to search on Google because I did.

Pasting a photo of search results is not a troubleshooting aid. I think SGS was just pointing out that a quick search for this issue yielded a lot of results for people who have documented troubleshooting the same issue.

If someone on the forum knows exactly how to fix your issue I am sure they will chime in. In the meanwhile, try combing through some of those search results and see if you can find the answer on your own.

I see you opened one link so far--good job, sorry it didn't help you. Don't give up.

What makes you say that? Just because it is affecting your install doesn't mean other people are experiencing the same thing. Keep in mind, a lot of people are running Gnome who have not been adding and deleting themes and related packages like you have been. :man_shrugging:

2 Likes

Virtualbox

I tried fresh install, and same issue.

Nope, it is not g00gle :slight_smile:

Reddit, 06.04.20?

1 Like

Post these:

ls /usr/share/pixmaps | grep -i text
ls /etc | grep -i release
grep "^LOGO=" /etc/os-release

In short...

  • Find the value of LOGO in file /etc/os-release
  • Create (if not exists) two files with names
/usr/share/pixmaps/$LOGO-text.svg
/usr/share/pixmaps/$LOGO-text-dark.svg

... obviously one is for light themes and the other for dark themes (background is dark).

I hope it works. I have no idea!!!

5 Likes

I just installed this on the metal to take a look and I can confirm that the logo is a broken icon for some reason.

Following Petsam's hint, I found these files:

ls /usr/share/pixmaps/ | grep -i text
.rw-r--r-- 4.5k root  6 Dec  2021  archlinux-logo-text-dark.svg
.rw-r--r-- 4.6k root  6 Dec  2021  archlinux-logo-text.svg
.rw-r--r-- 8.0k root  2 Apr 13:35  gnome-logo-text-dark.svg
.rw-r--r-- 8.0k root  2 Apr 13:35  gnome-logo-text.svg

And this clue:

grep "^LOGO=" /etc/os-release
LOGO=garudalinux

Copy the Gnome logo:

sudo cp /usr/share/pixmaps/gnome-logo-text.svg /usr/share/pixmaps/garudalinux-text.svg
sudo cp /usr/share/pixmaps/gnome-logo-text-dark.svg /usr/share/pixmaps/garudalinux-text-dark.svg

Presto!

Nice one Petsam, works like a charm. :blush:

4 Likes

Hi,

Thanks, working now.

sudo nano -w /usr/lib/os-release
LOGO=archlinux-logo

EDIT:

LOGO=garuda

:smiley:

1 Like

should be now fixed for all users

added the pixmap icons to garuda icons package

6 Likes
