Hi, I have an issue in my MacBook Pro with touchbar. The bar works as expected, I don’t have any issue with it, but when the computer has been idle for a while and I wake it, the touchbar changes from one appearance to another and the buttons don’t work anymore.
Here is my inxi and after are the images of what I am talking about
System:
Kernel: 6.12.1-arch1-Watanare-T2-1-t2 arch: x86_64 bits: 64 compiler: gcc
v: 14.2.1 clocksource: tsc avail: acpi_pm
parameters: BOOT_IMAGE=/@/boot/vmlinuz-linux-t2
root=UUID=3bc29ab7-b200-4649-9e39-07f78c9f7d51 rw rootflags=subvol=@
intel_iommu=on iommu=pt pcie_ports=compat quiet
resume=UUID=2be779c0-2258-41a6-9632-4c8988608bf2 loglevel=3
intel_iommu=on iommu=pt pcie_ports=compat ibt=off
Desktop: KDE Plasma v: 6.2.4 tk: Qt v: N/A info: frameworks v: 6.8.0
wm: kwin_wayland vt: 1 dm: SDDM Distro: Garuda base: Arch Linux
Machine:
Type: Laptop System: Apple product: MacBookPro16,3 v: 1.0
serial: <superuser required> Chassis: type: 9 v: Mac-E7203C0F68AA0004
serial: <superuser required>
Mobo: Apple model: Mac-E7203C0F68AA0004 v: MacBookPro16,3
serial: <superuser required> uuid: <superuser required> UEFI: Apple
v: 2022.100.22.0.0 (iBridge: 21.16.4222.0.0,0) date: 02/14/2024
Battery:
ID-1: BAT0 charge: 7.3 Wh (15.1%) condition: 48.5/58.2 Wh (83.3%)
volts: 10.9 min: 11.4 model: SMP bq20z451 type: Li-ion serial: N/A
status: discharging cycles: 322
CPU:
Info: model: Intel Core i5-8257U bits: 64 type: MT MCP arch: Coffee Lake
gen: core 8 level: v3 note: check built: 2017 process: Intel 14nm family: 6
model-id: 0x8E (142) stepping: 0xA (10) microcode: 0xF6
Topology: cpus: 1x dies: 1 clusters: 4 cores: 4 threads: 8 tpc: 2
smt: enabled cache: L1: 256 KiB desc: d-4x32 KiB; i-4x32 KiB L2: 1024 KiB
desc: 4x256 KiB L3: 6 MiB desc: 1x6 MiB
Speed (MHz): avg: 800 min/max: 400/3900 scaling: driver: intel_pstate
governor: powersave cores: 1: 800 2: 800 3: 800 4: 800 5: 800 6: 800 7: 800
8: 800 bogomips: 22412
Flags: avx avx2 ht lm nx pae sse sse2 sse3 sse4_1 sse4_2 ssse3 vmx
Vulnerabilities: <filter>
Graphics:
Device-1: Intel Coffee Lake-U GT3 [Iris Plus Graphics 645] vendor: Apple
driver: i915 v: kernel arch: Gen-9.5 process: Intel 14nm built: 2016-20
ports: active: eDP-1 empty: DP-1, DP-2, HDMI-A-1, HDMI-A-2 bus-ID: 00:02.0
chip-ID: 8086:3ea6 class-ID: 0300
Device-2: Apple FaceTime HD Camera (Built-in) driver: uvcvideo type: USB
rev: 2.0 speed: 480 Mb/s lanes: 1 mode: 2.0 bus-ID: 5-2:3 chip-ID: 05ac:8514
class-ID: 0e02 serial: <filter>
Device-3: Apple Touch Bar Display driver: appletbdrm,hid-multitouch,usbhid
type: USB rev: 2.0 speed: 480 Mb/s lanes: 1 mode: 2.0 bus-ID: 5-6:7
chip-ID: 05ac:8302 class-ID: 1000 serial: <filter>
Display: wayland server: X.org v: 1.21.1.14 with: Xwayland v: 24.1.4
compositor: kwin_wayland driver: X: loaded: modesetting
alternate: fbdev,intel,vesa dri: iris gpu: i915 display-ID: 0
Monitor-1: eDP-1 res: 2327x1455 size: N/A modes: N/A
API: EGL v: 1.5 hw: drv: intel iris platforms: device: 0 drv: iris
device: 1 drv: swrast gbm: drv: iris surfaceless: drv: iris wayland:
drv: iris x11: drv: iris
API: OpenGL v: 4.6 compat-v: 4.5 vendor: intel mesa v: 24.3.1-arch1.1
glx-v: 1.4 direct-render: yes renderer: Mesa Intel Iris Plus Graphics 645
(CFL GT3) device-ID: 8086:3ea6 memory: 3.71 GiB unified: yes
display-ID: :1.0
API: Vulkan v: 1.3.295 layers: 4 device: 0 type: integrated-gpu name: Intel
Iris Plus Graphics 645 (CFL GT3) driver: mesa intel v: 24.3.1-arch1.1
device-ID: 8086:3ea6 surfaces: xcb,xlib,wayland device: 1 type: cpu
name: llvmpipe (LLVM 18.1.8 256 bits) driver: mesa llvmpipe
v: 24.3.1-arch1.1 (LLVM 18.1.8) device-ID: 10005:0000
surfaces: xcb,xlib,wayland
Audio:
Device-1: Intel Cannon Point-LP High Definition Audio driver: snd_hda_intel
v: kernel alternate: snd_soc_avs,snd_sof_pci_intel_cnl bus-ID: 00:1f.3
chip-ID: 8086:9dc8 class-ID: 0403
Device-2: Apple Audio driver: aaudio pcie: gen: 3 speed: 8 GT/s lanes: 4
bus-ID: 02:00.3 chip-ID: 106b:1803 class-ID: 0401
Device-3: Apple Touch Bar Display driver: appletbdrm,hid-multitouch,usbhid
type: USB rev: 2.0 speed: 480 Mb/s lanes: 1 mode: 2.0 bus-ID: 5-6:7
chip-ID: 05ac:8302 class-ID: 1000 serial: <filter>
API: ALSA v: k6.12.1-arch1-Watanare-T2-1-t2 status: kernel-api tools: N/A
Server-1: PipeWire v: 1.2.7 status: active with: 1: pipewire-pulse
status: active 2: wireplumber status: active 3: pipewire-alsa type: plugin
4: pw-jack type: plugin tools: pactl,pw-cat,pw-cli,wpctl
Network:
Device-1: Broadcom BCM4377b Wireless Network Adapter vendor: Apple
driver: brcmfmac v: kernel pcie: gen: 2 speed: 5 GT/s lanes: 1
bus-ID: 01:00.0 chip-ID: 14e4:4488 class-ID: 0280
IF: wlan0 state: up mac: <filter>
Device-2: Broadcom BRCM4377 Bluetooth vendor: Apple driver: N/A
modules: hci_bcm4377 pcie: gen: 2 speed: 5 GT/s lanes: 1 port: N/A
bus-ID: 01:00.1 chip-ID: 14e4:5fa0 class-ID: 0280
IF-ID-1: enp2s0f1u1 state: down mac: <filter>
Info: services: iwd, NetworkManager, smbd, systemd-timesyncd
Drives:
Local Storage: total: 465.92 GiB used: 88.3 GiB (19.0%)
SMART Message: Unable to run smartctl. Root privileges required.
ID-1: /dev/nvme0n1 maj-min: 259:0 vendor: Apple model: SSD AP0512N
size: 465.92 GiB block-size: physical: 4096 B logical: 4096 B
speed: 31.6 Gb/s lanes: 4 tech: SSD serial: <filter> fw-rev: 1306
temp: 39.9 C scheme: GPT
Partition:
ID-1: / raw-size: 456.78 GiB size: 456.78 GiB (100.00%)
used: 88.3 GiB (19.3%) fs: btrfs dev: /dev/nvme0n1p2 maj-min: 259:2
ID-2: /boot/efi raw-size: 300 MiB size: 299.3 MiB (99.76%)
used: 628 KiB (0.2%) fs: vfat dev: /dev/nvme0n1p1 maj-min: 259:1
ID-3: /home raw-size: 456.78 GiB size: 456.78 GiB (100.00%)
used: 88.3 GiB (19.3%) fs: btrfs dev: /dev/nvme0n1p2 maj-min: 259:2
ID-4: /var/log raw-size: 456.78 GiB size: 456.78 GiB (100.00%)
used: 88.3 GiB (19.3%) fs: btrfs dev: /dev/nvme0n1p2 maj-min: 259:2
ID-5: /var/tmp raw-size: 456.78 GiB size: 456.78 GiB (100.00%)
used: 88.3 GiB (19.3%) fs: btrfs dev: /dev/nvme0n1p2 maj-min: 259:2
Swap:
Kernel: swappiness: 133 (default 60) cache-pressure: 100 (default) zswap: no
ID-1: swap-1 type: partition size: 8.8 GiB used: 0 KiB (0.0%) priority: -2
dev: /dev/nvme0n1p3 maj-min: 259:3
ID-2: swap-2 type: zram size: 7.6 GiB used: 1.53 GiB (20.1%) priority: 100
comp: lzo-rle avail: lzo max-streams: 8 dev: /dev/zram0
Sensors:
System Temperatures: cpu: 45.0 C pch: 47.0 C mobo: N/A
Fan Speeds (rpm): cpu: 1204
Info:
Memory: total: 8 GiB available: 7.61 GiB used: 4.09 GiB (53.8%)
Processes: 296 Power: uptime: 1h 17m states: freeze,mem,disk suspend: deep
avail: s2idle wakeups: 0 hibernate: platform avail: shutdown, reboot,
suspend, test_resume image: 3.03 GiB services: org_kde_powerdevil,
power-profiles-daemon, upowerd Init: systemd v: 256 default: graphical
tool: systemctl
Packages: 1562 pm: pacman pkgs: 1546 libs: 422
tools: gnome-software,octopi,paru,yay pm: flatpak pkgs: 16 Compilers:
gcc: 14.2.1 Shell: garuda-inxi default: fish v: 3.7.1 running-in: konsole
inxi: 3.3.36
Garuda (2.6.26-1):
System install date: 2024-04-26
Last full system update: 2024-12-06 ↻
Is partially upgraded: No
Relevant software: snapper NetworkManager dracut
Windows dual boot: No/Undetected
Failed units:
Normal working state:
After waking:
