Root Partition Mount Error

B1ack-D3ath · 22 July 2024 06:30

Hello everyone. I switched to garuda for about 1 month. I was using ubuntu before. My Linux knowledge is at an average level. The problem is exactly this. I use garuda alongside windows. When I started running out of memory for Garuda, I wanted to minimize a part of Windows and add it to Garuda. I used live usb garuda for this process. I first reduced the windows space with KDE Partition manager, then allocated the free space to Garuda. When my computer was restarting, it directed me to the (grub rescue) terminal screen. After connecting the partition with Garuda using the commands (set boot and set prefix), I was able to switch to the normal grub screen. The first thing I did after switching was to repair grub with Garuda Boot Repair. I realized the real problem after that. System, btrfs, package manager, everything is working, but I guess the disk connection is not formed properly. I cannot get any information about memory space at any point in the system. Neither the memory space nor the usable space is visible in the system monitor and dolphin.

Information about my system:

Disk information:
There are 2 physical disks in my computer. The first of these is my sda(hdd) disk where I keep my files and documents. It has a single partition and there is no information about the operating system. My second disk sdb(ssd) has 5 partitions:

sdb1 Boot
sdb2 Windows recovery part
sdb3 Windows operation system
sdb4 Garuda operation system
sdb5 Windows update temp directon

lsblk -f

NAME   FSTYPE FSVER LABEL UUID                                 FSAVAIL FSUSE% MOUNTPOINTS
sda
└─sda1 ntfs               01D8D43B6E0526E0
sdb
├─sdb1 vfat   FAT32       5E3D-7E9D                              60,5M    37% /boot/efi
├─sdb2
├─sdb3 ntfs               01DAAE9C4CBF5630
├─sdb4 btrfs              62ed85c1-1b65-4981-b158-3aabdba6a608                /var/log
└─sdb5 ntfs               01DA4DE7B9E38210
zram0

sudo fdisk -l

Disk /dev/sda: 465,76 GiB, 500106780160 bytes, 976771055 sectors
Disk model: ST500LM000-SSHD-
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 4096 bytes
I/O size (minimum/optimal): 4096 bytes / 4096 bytes
Disklabel type: gpt
Disk identifier: EF8CD400-3290-03AC-0035-E33BA40CEB00

Device     Start       End   Sectors   Size Type
/dev/sda1   2048 976769023 976766976 465,8G Microsoft basic data


Disk /dev/sdb: 465,76 GiB, 500107862016 bytes, 976773168 sectors
Disk model: SanDisk SDSSDH3
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disklabel type: gpt
Disk identifier: 9A245700-31AE-03AC-C015-89A66B0CEB00

Device         Start       End   Sectors   Size Type
/dev/sdb1       2048    206847    204800   100M EFI System
/dev/sdb2     206848    239615     32768    16M Microsoft reserved
/dev/sdb3     239616 284696575 284456960 135,6G Microsoft basic data
/dev/sdb4  284696576 974655487 689958912   329G Windows recovery environment
/dev/sdb5  974655488 976771071   2115584     1G Windows recovery environment


Disk /dev/zram0: 7,74 GiB, 8311537664 bytes, 2029184 sectors
Units: sectors of 1 * 4096 = 4096 bytes
Sector size (logical/physical): 4096 bytes / 4096 bytes
I/O size (minimum/optimal): 4096 bytes / 4096 bytes

garuda-inxi

System:
Kernel: 6.9.10-zen1-1-zen arch: x86_64 bits: 64 compiler: gcc v: 14.1.1
clocksource: tsc avail: hpet,acpi_pm
parameters: BOOT_IMAGE=/@/boot/vmlinuz-linux-zen
root=UUID=62ed85c1-1b65-4981-b158-3aabdba6a608 rw rootflags=subvol=@
quiet loglevel=3 ibt=off
Desktop: KDE Plasma v: 6.1.2 tk: Qt v: N/A info: frameworks v: 6.4.0
wm: kwin_wayland vt: 1 dm: SDDM Distro: Garuda base: Arch Linux
Machine:
Type: Laptop System: LENOVO product: 80Q7 v: Lenovo ideapad 300-15ISK
serial: <superuser required> Chassis: type: 10 v: Lenovo ideapad 300-15ISK
serial: <superuser required>
Mobo: LENOVO model: Paris 5A8 v: SDK0J40679 WIN
serial: <superuser required> part-nu: LENOVO_MT_80Q7_BU_idea_FM_Lenovo
ideapad 300-15ISK uuid: <superuser required> UEFI: LENOVO v: D5CN47WW
date: 08/26/2016
Battery:
ID-1: BAT0 charge: 24.7 Wh (100.0%) condition: 24.7/32.0 Wh (77.1%)
volts: 16.2 min: 14.4 model: SMP L15M4A01 type: Li-ion serial: <filter>
status: full
CPU:
Info: model: Intel Core i5-6200U bits: 64 type: MT MCP arch: Skylake
gen: core 6 level: v3 note: check built: 2015 process: Intel 14nm family: 6
model-id: 0x4E (78) stepping: 3 microcode: 0xF0
Topology: cpus: 1x cores: 2 tpc: 2 threads: 4 smt: enabled cache:
L1: 128 KiB desc: d-2x32 KiB; i-2x32 KiB L2: 512 KiB desc: 2x256 KiB
L3: 3 MiB desc: 1x3 MiB
Speed (MHz): avg: 988 high: 2753 min/max: 400/2800 scaling:
driver: intel_pstate governor: powersave cores: 1: 2753 2: 400 3: 400 4: 400
bogomips: 19200
Flags: avx avx2 ht lm nx pae sse sse2 sse3 sse4_1 sse4_2 ssse3 vmx
Vulnerabilities: <filter>
Graphics:
Device-1: Intel Skylake GT2 [HD Graphics 520] vendor: Lenovo driver: i915
v: kernel arch: Gen-9 process: Intel 14n built: 2015-16 ports: active: eDP-1
empty: DP-1,HDMI-A-1,HDMI-A-2 bus-ID: 00:02.0 chip-ID: 8086:1916
class-ID: 0300
Device-2: AMD Sun XT [Radeon HD 8670A/8670M/8690M / R5 M330 M430 Radeon
520 Mobile] vendor: Lenovo driver: radeon v: kernel alternate: amdgpu
arch: GCN-1 code: Southern Islands process: TSMC 28nm built: 2011-20 pcie:
gen: 3 speed: 8 GT/s lanes: 4 link-max: lanes: 8 bus-ID: 03:00.0
chip-ID: 1002:6660 class-ID: 0380 temp: 41.0 C
Device-3: Syntek Lenovo EasyCamera driver: uvcvideo type: USB rev: 2.0
speed: 480 Mb/s lanes: 1 mode: 2.0 bus-ID: 1-4:3 chip-ID: 174f:14e9
class-ID: 0e02 serial: <filter>
Display: wayland server: X.org v: 1.21.1.13 with: Xwayland v: 24.1.1
compositor: kwin_wayland driver: X: loaded: modesetting,radeon
alternate: fbdev,intel,vesa dri: iris,radeonsi gpu: i915,radeon
display-ID: 0
Monitor-1: eDP-1 res: 1607x904 size: N/A modes: N/A
API: EGL v: 1.5 hw: drv: intel iris drv: amd radeonsi platforms: device: 0
drv: radeonsi device: 1 drv: iris device: 2 drv: swrast gbm: drv: radeonsi
surfaceless: drv: radeonsi wayland: drv: iris x11: drv: iris
API: OpenGL v: 4.6 compat-v: 4.5 vendor: intel mesa v: 24.1.3-arch1.1
glx-v: 1.4 direct-render: yes renderer: Mesa Intel HD Graphics 520 (SKL GT2)
device-ID: 8086:1916 memory: 7.56 GiB unified: yes display-ID: :1.0
API: Vulkan v: 1.3.279 layers: 7 device: 0 type: integrated-gpu name: Intel
HD Graphics 520 (SKL GT2) driver: mesa intel v: 24.1.3-arch1.1
device-ID: 8086:1916 surfaces: xcb,xlib,wayland device: 1 type: cpu
name: llvmpipe (LLVM 18.1.8 256 bits) driver: mesa llvmpipe
v: 24.1.3-arch1.1 (LLVM 18.1.8) device-ID: 10005:0000
surfaces: xcb,xlib,wayland
Audio:
Device-1: Intel Sunrise Point-LP HD Audio vendor: Lenovo
driver: snd_hda_intel v: kernel alternate: snd_soc_skl,snd_soc_avs
bus-ID: 00:1f.3 chip-ID: 8086:9d70 class-ID: 0403
API: ALSA v: k6.9.10-zen1-1-zen status: kernel-api tools: N/A
Server-1: sndiod v: N/A status: off tools: aucat,midicat,sndioctl
Server-2: PipeWire v: 1.2.1 status: active with: 1: pipewire-pulse
status: active 2: wireplumber status: active 3: pipewire-alsa type: plugin
4: pw-jack type: plugin tools: pactl,pw-cat,pw-cli,wpctl
Network:
Device-1: Realtek RTL8111/8168/8211/8411 PCI Express Gigabit Ethernet
vendor: Lenovo driver: r8169 v: kernel pcie: gen: 1 speed: 2.5 GT/s lanes: 1
port: 4000 bus-ID: 01:00.0 chip-ID: 10ec:8168 class-ID: 0200
IF: enp1s0 state: down mac: <filter>
Device-2: Intel Dual Band Wireless-AC 3165 Plus Bluetooth driver: iwlwifi
v: kernel pcie: gen: 1 speed: 2.5 GT/s lanes: 1 bus-ID: 02:00.0
chip-ID: 8086:3166 class-ID: 0280
IF: wlp2s0 state: up mac: <filter>
Info: services: NetworkManager, smbd, systemd-timesyncd, wpa_supplicant
Bluetooth:
Device-1: Intel Bluetooth wireless interface driver: btusb v: 0.8 type: USB
rev: 2.0 speed: 12 Mb/s lanes: 1 mode: 1.1 bus-ID: 1-7:5 chip-ID: 8087:0a2a
class-ID: e001
Report: btmgmt ID: hci0 rfk-id: 2 state: up address: <filter> bt-v: 4.2
lmp-v: 8 status: discoverable: no pairing: no class-ID: 6c010c
Drives:
Local Storage: total: 931.52 GiB used: 71.1 GiB (7.6%)
SMART Message: Unable to run smartctl. Root privileges required.
ID-1: /dev/sda maj-min: 8:0 vendor: Seagate model: ST500LM000-SSHD-8GB
size: 465.76 GiB block-size: physical: 4096 B logical: 512 B speed: 6.0 Gb/s
tech: HDD rpm: 5400 serial: <filter> fw-rev: LVD5 scheme: GPT
ID-2: /dev/sdb maj-min: 8:16 vendor: SanDisk model: SDSSDH3 500G
size: 465.76 GiB block-size: physical: 512 B logical: 512 B speed: 6.0 Gb/s
tech: SSD serial: <filter> fw-rev: 30RL scheme: GPT
Partition:
ID-1: / raw-size: 329 GiB size: 329 GiB (100.00%) used: 71.06 GiB (21.6%)
fs: btrfs dev: /dev/sdb4 maj-min: 8:20
ID-2: /boot/efi raw-size: 100 MiB size: 96 MiB (96.00%)
used: 35.5 MiB (37.0%) fs: vfat dev: /dev/sdb1 maj-min: 8:17
ID-3: /home raw-size: 329 GiB size: 329 GiB (100.00%)
used: 71.06 GiB (21.6%) fs: btrfs dev: /dev/sdb4 maj-min: 8:20
ID-4: /var/log raw-size: 329 GiB size: 329 GiB (100.00%)
used: 71.06 GiB (21.6%) fs: btrfs dev: /dev/sdb4 maj-min: 8:20
ID-5: /var/tmp raw-size: 329 GiB size: 329 GiB (100.00%)
used: 71.06 GiB (21.6%) fs: btrfs dev: /dev/sdb4 maj-min: 8:20
Swap:
Kernel: swappiness: 133 (default 60) cache-pressure: 100 (default) zswap: no
ID-1: swap-1 type: zram size: 7.74 GiB used: 0 KiB (0.0%) priority: 100
comp: zstd avail: lzo,lzo-rle,lz4,lz4hc,842 max-streams: 4 dev: /dev/zram0
Sensors:
System Temperatures: cpu: 43.0 C pch: 35.5 C mobo: N/A gpu: radeon
temp: 41.0 C
Fan Speeds (rpm): N/A
Info:
Memory: total: 16 GiB available: 15.48 GiB used: 1.78 GiB (11.5%)
Processes: 206 Power: uptime: 10m states: freeze,mem,disk suspend: deep
avail: s2idle wakeups: 0 hibernate: platform avail: shutdown, reboot,
suspend, test_resume image: 6.18 GiB services: org_kde_powerdevil,
power-profiles-daemon, upowerd Init: systemd v: 256 default: graphical
tool: systemctl
Packages: pm: dpkg pkgs: 0 pm: pacman pkgs: 1812 libs: 501
tools: octopi,paru Compilers: clang: 18.1.8 gcc: 14.1.1 Shell: garuda-inxi
default: fish v: 3.7.1 running-in: konsole inxi: 3.3.35
Garuda (2.6.26-1):
System install date:     2024-07-04
Last full system update: 2024-07-21
Is partially upgraded:   No
Relevant software:       snapper NetworkManager dracut
Windows dual boot:       Probably (Run as root to verify)
Failed units:

petsam · 22 July 2024 16:23

Make sure your fstab has the correct UUID(s).
Use btrfs utilities to expand the available space to the new one.
Generally, prefer GParted for disk modifications. See how sdb4 is reported from fdisk, for example.

B1ack-D3ath · 23 July 2024 17:26

Thank you for trying to help, but I don’t quite understand what you mean. I would be very happy if you could explain the steps I need to do in a little more detail.

petsam · 23 July 2024 18:19

I would appreciate it, if you had already searched about them, to try not becoming a help vampire.

When modifying a partition, it is usually assigned a different/new UUID. That new UUID must be updated in /etc/fstab (fstab is crucial file for the system to detect the corect partitions to use).

Here, you have not used UUID for connecting the proper partitions to the system. This makes it very probable that UUID(s) may have changed.

BTRFS requires special actions to take extra space, even if the partition is resized with disk utilities. Archwiki has relevant instructions for this, as well as the manual (man btrfs).

This is probably a bug in fdisk, kdepartitionmanager, or somewhere else.
Who knows?
That’s why we should prefer the most reliable tools for each task, which is GParted in this case.

B1ack-D3ath · 26 July 2024 14:26

I’m sorry you feel that way, I wasn’t trying to fake vampire help. I had already checked the fstab file. uuids were already done correctly. I used the sudo btrfs resize max / command when expanding the space. But thanks to you I realized that sdb4 is windows recovery area. I think this is the problem I need to fix. Thank you for your help. I’m leaving my fstab file below in case anyone else encounters this problem.

# /etc/fstab: static file system information.
#
# Use 'blkid' to print the universally unique identifier for a device; this may
# be used with UUID= as a more robust way to name devices that works even if
# disks are added and removed. See fstab(5).
#
# <file system>             <mount point>  <type>  <options>  <dump>  <pass>
UUID=5E3D-7E9D                            /boot/efi      vfat    defaults,umask=0077 0 2
UUID=62ed85c1-1b65-4981-b158-3aabdba6a608 /              btrfs   subvol=/@,defaults,noatime,compress=zstd 0 0
UUID=62ed85c1-1b65-4981-b158-3aabdba6a608 /home          btrfs   subvol=/@home,defaults,noatime,compress=zstd 0 0
UUID=62ed85c1-1b65-4981-b158-3aabdba6a608 /root          btrfs   subvol=/@root,defaults,noatime,compress=zstd 0 0
UUID=62ed85c1-1b65-4981-b158-3aabdba6a608 /srv           btrfs   subvol=/@srv,defaults,noatime,compress=zstd 0 0
UUID=62ed85c1-1b65-4981-b158-3aabdba6a608 /var/cache     btrfs   subvol=/@cache,defaults,noatime,compress=zstd 0 0
UUID=62ed85c1-1b65-4981-b158-3aabdba6a608 /var/log       btrfs   subvol=/@log,defaults,noatime,compress=zstd 0 0
UUID=62ed85c1-1b65-4981-b158-3aabdba6a608 /var/tmp       btrfs   subvol=/@tmp,defaults,noatime,compress=zstd 0 0
tmpfs                                     /tmp           tmpfs   defaults,noatime,mode=1777 0 0
