The problem is caused by xf86-video-nouveau , which is bound to garuda-video-linux-config . Therefore, you can only uninstall the package that is bundled with garuda-video-linux-config .
It fix:
#Install os on live
yay -Rsc xf86-video-nouveau
yay -Sy nvidia-prime nvidia-dkms nvidia-utils lib32-nvidia-utils nvidia-settings garuda-nvidia-config garuda-nvidia-config linux-lts linux-lts-headers --needed
garuda-update
#add /etc/default/grub:
GRUB_CMDLINE_LINUX_DEFAULT='nvidia-drm.modeset=1'
sudo grub-mkconfig -o /boot/grub/grub.cfg
#Boot using lts kernel
Sometimes it was blurry when I started it before it was repaired:
In Garuda Live, I selected the Nvidia boot option. At this time, it worked normally in both X11 and Wayland and could use two screens. After I installed the system and booted it up, the driver seemed to get a bit weird. It could not read my second monitor normally, both in X11 and Wayland.
I got some packages from another system to fix the dual screen display in X11, but the problem still exists in Wayland:
yay -Rsc --noconfirm --noprogressbar --nodeps lib32-nvidia-utils xf86-video-nouveau
yay -Syuq --noconfirm --noprogressbar --needed nvidia-hook nvidia-prime nvidia-dkms nvidia-settings
nvidia-installer-kernel-para nvidia-drm.modeset=1 add
I hope that after I install the system, I can use Garuda’s built-in driver to display normally without frequently operating anything.
λ garuda-inxi
System:
Kernel: 6.1.66-1-lts arch: x86_64 bits: 64 compiler: gcc v: 13.2.1
clocksource: tsc available: acpi_pm
parameters: BOOT_IMAGE=/@/boot/vmlinuz-linux-lts
root=UUID=49b0511d-6878-4919-9909-f6f569ab1a2a rw rootflags=subvol=@
quiet resume=UUID=910d388a-9bc3-42b7-b7e5-227f9cd546dd loglevel=3
nvidia-drm.modeset=1 splash sysrq_always_enabled=1
systemd.unified_cgroup_hierarchy=1 nowatchdog nvme_load=YES ibt=off
Desktop: KDE Plasma v: 5.27.10 tk: Qt v: 5.15.11 wm: kwin_wayland vt: 1
dm: SDDM Distro: Garuda Linux base: Arch Linux
Machine:
Type: Laptop System: LENOVO product: 82RF v: Legion Y9000P IAH7H
serial: <superuser required> Chassis: type: 10 v: Legion Y9000P IAH7H
serial: <superuser required>
Mobo: LENOVO model: LNVNB161216 v: 31900002 WIN
serial: <superuser required> UEFI: LENOVO v: J2CN54WW date: 07/10/2023
Battery:
ID-1: BAT0 charge: 75.1 Wh (100.0%) condition: 75.1/80.0 Wh (93.9%)
volts: 16.7 min: 15.4 model: Sunwoda L21D4PC1 type: Li-poly serial: <filter>
status: full cycles: 38
CPU:
Info: model: 12th Gen Intel Core i7-12700H bits: 64 type: MST AMCP
arch: Alder Lake gen: core 12 level: v3 note: check built: 2021+
process: Intel 7 (10nm ESF) family: 6 model-id: 0x9A (154) stepping: 3
microcode: 0x430
Topology: cpus: 1x cores: 14 mt: 6 tpc: 2 st: 8 threads: 20 smt: enabled
cache: L1: 1.2 MiB desc: d-8x32 KiB, 6x48 KiB; i-6x32 KiB, 8x64 KiB
L2: 11.5 MiB desc: 6x1.2 MiB, 2x2 MiB L3: 24 MiB desc: 1x24 MiB
Speed (MHz): avg: 775 high: 1673 min/max: 400/4600:4700:3500 scaling:
driver: intel_pstate governor: powersave cores: 1: 518 2: 527 3: 1275 4: 400
5: 652 6: 400 7: 1673 8: 1387 9: 1299 10: 400 11: 1455 12: 1083 13: 400
14: 400 15: 400 16: 400 17: 677 18: 400 19: 699 20: 1061 bogomips: 107560
Flags: avx avx2 ht lm nx pae sse sse2 sse3 sse4_1 sse4_2 ssse3 vmx
Vulnerabilities: <filter>
Graphics:
Device-1: Intel Alder Lake-P GT2 [Iris Xe Graphics] vendor: Lenovo
driver: i915 v: kernel arch: Gen-12.2 process: Intel 10nm built: 2021-22+
ports: active: eDP-1 empty: DP-1,DP-2 bus-ID: 0000:00:02.0
chip-ID: 8086:46a6 class-ID: 0300
Device-2: NVIDIA GA104M [Geforce RTX 3070 Ti Laptop GPU] vendor: Lenovo
driver: nvidia v: 545.29.06 alternate: nouveau,nvidia_drm non-free: 545.xx+
status: current (as of 2023-10; EOL~2026-12-xx) arch: Ampere code: GAxxx
process: TSMC n7 (7nm) built: 2020-2023 ports: active: none off: DP-4
empty: DP-3,HDMI-A-1,eDP-2 bus-ID: 0000:01:00.0 chip-ID: 10de:24e0
class-ID: 0300
Display: wayland server: X.org v: 1.21.1.9 with: Xwayland v: 23.2.2
compositor: kwin_wayland driver: X: loaded: modesetting,nvidia
unloaded: nouveau alternate: fbdev,intel,nv,vesa dri: iris
gpu: i915,nvidia d-rect: 4480x2800 display-ID: 0
Monitor-1: DP-4 pos: bottom-l res: 1920x1200 size: N/A modes: N/A
Monitor-2: eDP-1 pos: top-right res: 2560x1600 size: N/A modes: N/A
API: EGL v: 1.5 hw: drv: intel iris drv: nvidia platforms: device: 0
drv: nvidia device: 1 drv: iris device: 3 drv: swrast gbm: drv: iris
surfaceless: drv: nvidia wayland: drv: iris x11: drv: iris
inactive: device-2
API: OpenGL v: 4.6.0 compat-v: 4.5 vendor: intel mesa v: 23.2.1-arch1.2
glx-v: 1.4 direct-render: yes renderer: Mesa Intel Graphics (ADL GT2)
device-ID: 8086:46a6 memory: 14.98 GiB unified: yes display-ID: :1.0
API: Vulkan v: 1.3.269 layers: 8 device: 0 type: integrated-gpu name: Intel
Graphics (ADL GT2) driver: mesa intel v: 23.2.1-arch1.2
device-ID: 8086:46a6 surfaces: xcb,xlib,wayland device: 1
type: discrete-gpu name: NVIDIA GeForce RTX 3070 Ti Laptop GPU
driver: nvidia v: 545.29.06 device-ID: 10de:24e0
surfaces: xcb,xlib,wayland device: 2 type: cpu name: llvmpipe (LLVM
16.0.6 256 bits) driver: mesa llvmpipe v: 23.2.1-arch1.2 (LLVM 16.0.6)
device-ID: 10005:0000 surfaces: xcb,xlib,wayland
Audio:
Device-1: Intel Alder Lake PCH-P High Definition Audio vendor: Lenovo
driver: snd_hda_intel v: kernel alternate: snd_sof_pci_intel_tgl
bus-ID: 0000:00:1f.3 chip-ID: 8086:51c8 class-ID: 0403
Device-2: NVIDIA GA104 High Definition Audio vendor: Lenovo
driver: snd_hda_intel v: kernel bus-ID: 0000:01:00.1 chip-ID: 10de:228b
class-ID: 0403
API: ALSA v: k6.1.66-1-lts status: kernel-api tools: N/A
Server-1: PipeWire v: 1.0.0 status: active with: 1: pipewire-pulse
status: active 2: wireplumber status: active 3: pipewire-alsa type: plugin
4: pw-jack type: plugin tools: pactl,pw-cat,pw-cli,wpctl
Network:
Device-1: Intel Alder Lake-P PCH CNVi WiFi driver: iwlwifi v: kernel
bus-ID: 0000:00:14.3 chip-ID: 8086:51f0 class-ID: 0280
IF: wlp0s20f3 state: up mac: <filter>
Device-2: Realtek RTL8111/8168/8411 PCI Express Gigabit Ethernet
vendor: Lenovo driver: r8169 v: kernel port: 3000 bus-ID: 0000:32:00.0
chip-ID: 10ec:8168 class-ID: 0200
IF: enp50s0 state: down mac: <filter>
Bluetooth:
Device-1: Intel AX211 Bluetooth driver: btusb v: 0.8 type: USB rev: 2.0
speed: 12 Mb/s lanes: 1 mode: 1.1 bus-ID: 3-10:7 chip-ID: 8087:0033
class-ID: e001
Report: btmgmt ID: hci0 rfk-id: 2 state: up address: <filter> bt-v: 5.3
lmp-v: 12 status: discoverable: no pairing: no class-ID: 7c010c
RAID:
Hardware-1: Intel Volume Management Device NVMe RAID Controller driver: vmd
v: 0.6 port: N/A bus-ID: 0000:00:0e.0 chip-ID: 8086:467f rev: class-ID: 0104
Drives:
Local Storage: total: 1.4 TiB used: 16.62 GiB (1.2%)
SMART Message: Unable to run smartctl. Root privileges required.
ID-1: /dev/nvme0n1 maj-min: 259:6 vendor: Kingbank model: KP260
size: 953.87 GiB block-size: physical: 512 B logical: 512 B speed: 63.2 Gb/s
lanes: 4 tech: SSD serial: <filter> fw-rev: SN07443 temp: 52.9 C
scheme: GPT
ID-2: /dev/nvme1n1 maj-min: 259:0 vendor: SanDisk
model: SKHynix HFS512GEJ9X115N size: 476.94 GiB block-size: physical: 512 B
logical: 512 B speed: 63.2 Gb/s lanes: 4 tech: SSD serial: <filter>
fw-rev: 51010A12 temp: 55.9 C scheme: GPT
Partition:
ID-1: / raw-size: 936.7 GiB size: 936.7 GiB (100.00%) used: 16.61 GiB (1.8%)
fs: btrfs dev: /dev/nvme0n1p2 maj-min: 259:8
ID-2: /boot/efi raw-size: 300 MiB size: 299.4 MiB (99.80%)
used: 4.7 MiB (1.6%) fs: vfat dev: /dev/nvme0n1p1 maj-min: 259:7
ID-3: /home raw-size: 936.7 GiB size: 936.7 GiB (100.00%)
used: 16.61 GiB (1.8%) fs: btrfs dev: /dev/nvme0n1p2 maj-min: 259:8
ID-4: /var/log raw-size: 936.7 GiB size: 936.7 GiB (100.00%)
used: 16.61 GiB (1.8%) fs: btrfs dev: /dev/nvme0n1p2 maj-min: 259:8
ID-5: /var/tmp raw-size: 936.7 GiB size: 936.7 GiB (100.00%)
used: 16.61 GiB (1.8%) fs: btrfs dev: /dev/nvme0n1p2 maj-min: 259:8
Swap:
Kernel: swappiness: 133 (default 60) cache-pressure: 100 (default) zswap: no
ID-1: swap-1 type: partition size: 16.87 GiB used: 0 KiB (0.0%)
priority: -2 dev: /dev/nvme0n1p3 maj-min: 259:9
ID-2: swap-2 type: zram size: 15.34 GiB used: 0 KiB (0.0%) priority: 100
comp: zstd avail: lzo,lzo-rle,lz4,lz4hc,842 max-streams: 20 dev: /dev/zram0
Sensors:
System Temperatures: cpu: 61.0 C mobo: N/A
Fan Speeds (rpm): N/A
Info:
Processes: 387 Uptime: 7m wakeups: 0 Memory: total: 16 GiB note: est.
available: 15.34 GiB used: 6.58 GiB (42.9%) Init: systemd v: 255
default: graphical tool: systemctl Compilers: gcc: 13.2.1 Packages:
pm: pacman pkgs: 1326 libs: 375 tools: octopi,paru Shell: fish v: 3.6.2
running-in: konsole inxi: 3.3.31
Garuda (2.6.19-2):
System install date: 2023-12-10
Last full system update: 2023-12-10
Is partially upgraded: No
Relevant software: snapper NetworkManager dracut nvidia-dkms
Windows dual boot: Probably (Run as root to verify)
Failed units:
